規(guī)格 |
L |
HxY |
D1 |
V |
D2 |
D3 |
|
DN6 |
72 |
21X21 |
6 |
41 |
19 |
25.4 |
|
DN8 |
72 |
21X21 |
8 |
41 |
19 |
25.4 |
|
DN10 |
72 |
21X21 |
10 |
41 |
19 |
25.4 |
|
DN15 |
108 |
36X32 |
13 |
61 |
19 |
25.4 |
|
DN20 |
126 |
48X55 |
16 |
72 |
43.5 |
50.5 |
|
DN25 |
126 |
48X55 |
22 |
72 |
43.5 |
50.5 |
|
DN32 |
160 |
70X64 |
29 |
92 |
43.5 |
50.5 |
|
DN40 |
160 |
70X64 |
35 |
92 |
43.5 |
50.5 |
|
DN50 |
193 |
85X75 |
49 |
112 |
56.5 |
64 |
|
DN65 |
220 |
105X91 |
59 |
138 |
70.5 |
77.5 |
|
DN70 |
256 |
126X114 |
72 |
190 |
83.5 |
91 |
|
DN80 |
256 |
126X114 |
85 |
190 |
97 |
106 |
|
DN100 |
350 |
194X8 |
98 |
250 |
110 |
119 |
|
DN125 |
350 |
194X8 |
125 |
250 |
146 |
155 |
